Technical Specifications of King Long 9 meters 27 seats public transport bus
| MODEL | XMQ6900G |
| DIRECTION | LHD |
| DIMENSIONS | |
| Length*Width*Height (mm) | 8990×2450×3050,3140 |
| Wheelbase (mm) | 4250 |
| Front overhang/rear overhang (mm) | 1990/2750 |
| Minimum ground clearance (mm) | |
| CAPACITY | |
| Seating arrangement | 27+1 |
| Fuel tank capacity (L) | 150 |
| ENGINE | |
| Brand | YUCHAI |
| Model | YC6J200-50 |
| Emission standard | Euro V |
| Rated power (kw/rpm) | 147/2500 |
| Rated torque (N.m/rpm) | 730/1200~1700 |
| Displacement (L) | 6.494 |
| TRANSMISSION & CLUTCH | |
| Transmission | Manual transmission |
| AXLES | |
| Front | DONGFENG axle |
| Rear | DONGFENG axle |
| SUSPENSION | |
| Suspension system | Multiple-leaf spring |
| STEERING | |
| Steering system | Chinese |
| Brake system | |
| Brake system (Disc/Drum) | Front/Rear Drum |
| Tyre | 9R22.5 |
| ABS | ABS |
| Body | |
| DOOR & WINDOW | |
| Doors | Front inner-swing doors, two of the middle inner-swing door |
| Side Windows | Aluminium alloy sliding windows |
| SEATS | |
| Driver | Mechanical damping driver seat(with three-point safety belt) |
| Passenger | KING LONG passenger seat |
| AIR CONDITIONER | |
| Type | - |
| HEATER | |
| Type | No heater, engine waste heat for defrosting |
| MIRROR | |
| Type | Wide vision rear view mirror |
| OTHER STANDARD EQUIPMENT | |
| Flat paint, engine cabin automatic fire extinguisher | |
